Arntz Band Saw Bi-Metal M42 Star
Arntz Band Saw Bi-Metal M42 Star
Arntz Band Saw Bi-Metal M42 Star
Hover to Zoom

Last Updated
27 Oct 2020
Country Origin
Germany
Minimum Order
1 unit

Specification of

ARNTZ BAND SAW BI-METAL M42 STAR
Arntz Band Saw Bi-Metal M-42 STAR

Band saw is use for cutting any type of steel or iron material, granite, and glass using Bandsaw as intended.


All rounder for solid, small-dimensioned materials.
Engineered for:
Common steel qualities and non ferrous metals
Short-chipping materials
Small structurals with thin walls
Narrow cross sections up to approx. 100 mm (4")
Contour cutting operations

PT SINAR MENTARI JAYA is an Authorized Arntz® distributor in Indonesia.
We have established good relations with Arntz Germany since 2002


Please contact us for more detail information

TECHNICAL RECOMENDATIONS:


For Bi-Metal Band Saw Blades



Material groups

Material specification DIN

Material no.

Cutting speed Vc (m/min)

Cooling fluids

CS1/CS2-Plus

Bi-Metal

Cutting oil

Emulsion

Structural steels

St 37 – 2

1.0037

30-50

80-100



x

St 50 – 2

1.0050

30-45

60-85



x

St 60 – 2

1.0060

30-40

50-70



x

Case-hardening steels

C 10

1.0301

40-60

80-100

x



14 NiCr 14

1.5752

25-30

40-55

x



21 NiCrMo 2

1.6523

30-40

50-60

x



16 MnCr 5

1.7131

25-30

40-60

x



Free machining steels

9 S 20

1.0711

40-60

80-120



x

45 S 20

1.0727

40-60

80-120



x

Heat treatable steels

C 45

1.0503

35-50

60-70



x

40 Mn 4

1.1157

30-40

60-70



x

36 NiCr 6

1.5710

30-40

60-70



x

34 CrNiMo 6

1.6582

25-35

50-65



x

42 CrMo 4

1.7225

25-35

50-65



x

Ball bearing steels

100  Cr 6

1.3505

20-30

35-50



x

100 CrMn 6

1.3520

20-30

35-50



x

Spring steels

65 Si 7

1.5028

25-35

45-60



x

50 CrV 4

1.8159

25-35

45-60



x

Unalloyed tool steels

C 125 W C 75 W

1.1663

20-30

40-60



x



1.1750

20-30

40-60



x

Cold-work tool steels

125  Cr 1

1.2002

20-30

40-50

x

x

X 210  Cr 12

1.2080

15-25

30-40

x

x

X 155 CrVMo 12 1

1.2379

15-25

30-40

dry

x

X 42 Cr 13

1.2083

20-25

35-45

x

x

X 165  CrV 12

1.2201

15-25

30-45

x

x

100 CrMo 5

1.2303

15-30

30-50

x

x

X 32 CrMoV 3 3

1.2365

25-35

45-60

x

x

45 WCrV 7

1.2542

20-30

40-50

x



Hot-work tool steels

56 NiCrMoV 7

1.2714

20-30

40-50

x

x

High speed steels

S 6-5-2-5  (E Mo5  Co5) S 2-10-1-8  (M 42)

1.3243

20-30

35-45



x

S 6-5-2  (DMo5)

1.3247

20-30

35-45



x



1.3343

20-30

35-45



x

Vave steels

X 45 CrSi 9 3

1.4718

30-45

x

x

X 45 CrNiW 18 9

1.4873

-

30-40

x

x

High temerature steels

X 20 CrMoV 12 1

1.4922

10-30

x

x

X 5 NiCrTi 26 15

1.4980

-

10-30

x

x

Heat resistant steels

X 10 CrSi 6

1.4712

15-25

x

x

X 10 CrAl 18

1.4742

15-25

x

x

X 15 CrNiSi 25 20

1.4841

-

15-25

x

x

Stainless steels

X 5 CrNi 18 10 (V2A)

1.4301

30-40

x

x

X 6 CrNiMoTi 172 12 2 (V4A)

1.4571

-

30-40

x

x

Steal castings

GS-38

1.0420

20-30

40-60



x

GS-60

1.0558

20-30

40-60



x

Cast irons

GG-15

0.6015

25-30

30-60

dry



GG-30

0.6030

25-30

30-60

dry



GGG-50

0.7050

25-30

30-60

dry



GTW-40

1.8040

25-30

30-60

dry



GTS-65

1.8165

25-30

30-60

dry



Copper

KE-Cu

2.0050

100-250

100-400

x

x

Elektrolyt-Copper



100-250

100-400

x

x

Brass (copper-zinc alloys)

CuZn 10

2.0230

100-300

100-400



x

CuZn 31 Si 1

2.0490

100-250

100-400



x

Aluminium bronze (copper-aluminium alloys)

CuAl 8

2.0920

20-30

35-50



x

CuAl 10 Fe 3 Mn 2

2.0936

20-30

35-50



x

Bronze (copper-TIN alloys)

CuSn 6

2.1020

80-100

80-150



x

CuSn 6 Zn 6

2.1080

80-100

80-150



x

Red brass (copper-cast alloys)

CuSn 10 Zn

2.1086

30-40

50-100



x

CuSn 5 ZnPb

2.1096

30-40

50-100



x

Nickel base alloys

NiCr 20 TiAl

2.4631

10-25

x

x

NiCr 22 FeMo

2.4972

-

10-25

x

x

Aluminium and aluminium alloys

Al 99.5

3.0255

80-300

80-800



x

AlMgSiPb

3.0615

80-300

80-800



x

G-AlSi 5 Mg

3.2341

80-300

80-800



x

Titanium and titanium alloys

Ti Grade 1

3.7025

10-20

x

x

TiAl 6 V 4

3.7164

-

10-20

x

x

Thermoplatic plastics

PVC



100-400

100-400

dry



Teflon, Hostalen



100-400

100-400

dry



Plastics with fibre inlays

Resitex



50-200

50-300

dry



Novotex



50-200

50-300

dry





For Carbide Band Saw Blades

For Cutting Steel

Material group

Material specifications DIN

Material no.

Cutting speed

Recommended tooth pitch material dimensions

Vc(m/min)

75 - 140 mm

100 - 350 mm

300 - 550 mm

over 540 mm

Structural steels

St 37/42

1.0037/1.0042

100-130

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

St 52/60

1.0050/1.0060

90-120

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Case-hardening steels

C10/C15

1.0301/1.0401

110-140

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

16 MnCr 5

1.7131

80-100

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

20 CrMo 5

17264

80-100

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

21 NiCrMo 2

16523

70-90

3/4 K

3 tpi  2/3 K

14/2  K

0.75/1.25  K

Nitrate steels

34 CrAlNi 7

18550

45-60

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

34 CrAlMo 5

18507

45-60

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Free machining steels

9 S 20

10711

100-160

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Heat treatable steels

C 35/45

1.0501/1.0503

90-120

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

42 CrMo 4

17225

70-90

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

34 CrNiMo 6

16582

70-90

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Ball bearing steels

100 Cr 6

13505

70-90

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

100 CrMo 7 3

13536

65-85

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Spring steels

65 Si 7

15028

65-85

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

50 CrV 4

18159

65-85

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Unalloyed tool steels

C 125 W

11663

65-80

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

C 80 W 1

11525

70-85

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Cold-work tool steels

125 Cr 1

12002

65-80

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

X 210 Cr 12

12080

40-50

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

X 155 CrVMO 12 1

12379

40-50

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

90 MnCrV 8

12842

45-55

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Hot-work tool steels

40 CrMnMo 7

12311

70-90

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

X 40 CrMoV 5 1

12344

60-80

3/4 K

3 tpi  2/3 K

1.4/2  K

0,75/1.25  K

56 NiCrMoV 7

12714

50-70

3/4 K

3 tpi  2/3 K

1.4/2  K

0,75/1.25  K

40 CrMnNiMo 8 6 4

12738

35-50

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

High speed steels

S 6-5-2

13343

50-60

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

S 3-3-2

13333

55-65

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

S 2-10-1-8

13247

45-60

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

S 10-4-3-10

13207

45-60

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

S 18-0-1

13355

45-60

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Stainless steels

X 5 CrNi 18 10

14301

70-80

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

X 6CrNiMoTi 17 122

14571

65-75

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

X 20 Cr 13

14021

80-100

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Valve steels

X 45 CrSi 9 3

14718

50-60

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

X 45 CrNiW 18 9

14873

40-50

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

High temperature steels

X 12 CrCoNi 21 20

14971

30-40

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

X 20 CrMoWV 12 1

14935

80-100

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Heat resistant steels

X 15 CrNiSi 25 20

14841

30-40

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

X 12 NiCrSi 36 16

14864

30-40

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Special alloys

NiCr 19 NbMo

24668

20-30

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

NiMo 30

24810

22-35

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

NiCr 13 Mo 6 Ti 3

24662

20-30

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

NiCo 20 Cr 20 MoTi

24650

22-35

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

X 8 CrNiAlTi 20 20

14847

22-35

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Heat treated steels















1000 - 1200 N/mm2





35-50

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

1200 - 1400 N/mm2





30-45

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

1400 - 1600 N/mm2





25-35

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Hardened steels















50 HRC





15-20

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

55 HRC





42278

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

60 HRC





43442

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Steel castings

GS-38

10420

70-100

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

GS-60

10558

60-85

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

Cast irons

GG-30

4,1875

60-80

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K

GGG-50

0.7050

55-75

3/4 K

3 tpi  2/3 K

1.4/2  K

0.75/1.25  K



For Carbide Band Saw Blades

For cutting non ferrous metals

Material group

Material specifications DIN

Material no.

Cutting  speed

Recommended tooth pitch Material dimensions

Vc (m/min)

75 - 140 mm

100 - 350 mm

300 - 550 mm

ab 540 mm

Aluminium and  aluminium alloys

Al 99,5

30255

up to 3000 m/min.

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

AlMg 1

33315

up to 3000 m/min.

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

AlMg 3

33535

up to 3000 m/min.

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

AlMg 4.5Mn

33547

up to 3000 m/min.

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

AlMgSi 1

32315

up to 3000 m/min.

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

Copper

KE-Cu

20050

100-200

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

E-Cu

20060

100-200

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

Brass (copper-zinc alloys)

CuZn 39 Pb 3

20401

150-250

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

VuZn 31 Si

20230

150-250

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

Bronze

CuSn 6

21020

90-130

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

Red brass

CuSn 5 ZnPb

21096

90-130

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

CuSn 10 Zn

21086

90-130

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25 K

Aluminium-Bronze

CuAl 8

20920

60-80

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

CuAl 8 Fe 38

2.0920.60

52-65

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

CuAl 10 Ni 5 Fe 4

20966

50-70

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

Titanium and  titanium alloys

Ti Grade 1

37025

80-100

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

TiAl 6 V 4

37164

60-90

3/4 K

3 tpi  2/3 K

1,4/2  K

0.75/1.25  K

Untuk keterangan lebih lanjut, silahkan download PDF ini :

Ulasan

/5
Ulasan
5
4
3
2
1

Foto dari Pembeli

Ulasan dari Pembeli

Filter
Semua
Dengan Foto
5
4
3
2
1
Telepon
Request a Quote
Produk Siap di Pesan
Rp 0
1

Bendera Indonesia Indonesia  |  Bendera Inggris English
Ingin menghubungi kami?
Klik tombol dibawah
Logo IDT
Chatbot
